W50TB carries on the window heritage in its most authentic form, proposing the same forms, proportions and overlapping efects of the CLASSIC W20 and W40 steel window profiles, now refined and evolved thanks to modern technologies.
The innovative high density polyurethane isolator used as thermal barrier, together with the possibility of housing high performance double pane glass up to 37 mm, allow to fully respond to current regulations and contemporary needs for comfort, also in harsher weather conditions, where the traditional steel windows may not be sufficient. Availability of a wide range of exclusive fittings in several finishes, reproduced from original designs of the modern era. Any kind of inward or outward openings: side-hung, double-vent (French style), bottom-hung, top-hung or projected top-hung, horizontally and vertically pivoted windows, as well as large sliding and folding doors.
Download Modern W50TB Brochure
Standard door handles:
Available in any RAL colour
Non standard door handles:
B850
Available colours:
- Satin Chrome
- Brushed Copper
- Brushed Brass
- RTD (Dark Bronze)
- Gun Metal
- Antique Black
- Oil Rub Bronze
B860
Available colours:
- Satin Chrome
- Brushed Copper
- Brushed Brass
- RTD (Dark Bronze)
- Gun Metal
- Antique Black
- Oil Rub Bronze
Features of W50TB
- Precision cold formed steel profiles
- “Stepped leg” design
- High density cast in polyurethane isolator
- Very compact profiles with minimal depth and sightlines
- Mechanically fixed non-shrinking gaskets
- Low emissivity double-glazing up to 37 mm
- Choice of different glazing beads
- Zinc-magnesium pre-coating for corrosion protection
Standard colours:
Other RAL colours available!
All our W50TB windows are internally beaded for enhanced security
All windows and doors can be glazed with units up to 37mm (tripleglazed) with a U-value 0,7W/m2K and in standard comes with low emission coating
Within required by Building Regulation areas included is safety glazing
We also offer additionally ranges of coloured, toughened, laminated glass for extra security. Some other available glass options:
- Triple glazed units for sound reduction and energy efficiency
- Acoustic
- Solar control
- Self-cleaning
- Digital print units
- Ornamental
